TECHNICAL SPECIFICATIONS

DIMENSIONS Length 1800 mm
Width 700 mm
Height 1050 mm
Seat Height 720 mm
Ground Clearance 190 mm
Pay Load 250 Kg
Kerb Weight 80 Kg
BATTERY Type LFP Li-ion
Voltage(V) 60 V
Capacity (Ah) 23 Ah
MOTOR Type BLDC
Voltage(V) 60 V
Peak Power 2100 W
TRANSMISSION SYSTEM Transmission System Wheel Hub Motor
PERFORMANCE Speed 45 km
Range 70 km
Gradeability > 13 deg
BRAKING SYSTEM Front Brake Disc Brake
Rear Brake Disc Brake
SUSPENSION SYSTEM Front Telescopic Fork
Rear Double Shocker
TYRE Type Tubeless Tyre
Front Tyre 3.0-10”
Rear Tyre 90/90-12”
LAMPS Head Lamp LED Type
Front & Rear Direction Indicator LED Type
Tail Lamp LED Type
INSTRUMENT CLUSTER Instrument Cluster Digital
CHARGER Charger 4-7 A
