TECHNICAL SPECIFICATIONS

DIMENSIONS Length 1785 mm
Width 700 mm
Height 1100 mm
Seat Height 725 mm
Ground Clearance 200 mm
Pay Load 150 Kg
Kerb Weight 75 Kg
BATTERY Type LFP Li-ion
Voltage(V) 60 V
Capacity (Ah) 15Ah / 23 Ah
MOTOR Type BLDC
Voltage(V) 60 V
Peak Power 250 W
TRANSMISSION SYSTEM Transmission System Wheel Hub Motor
PERFORMANCE Speed 25 km
Range 80 km
Gradeability > 13 deg
BRAKING SYSTEM Front Brake Disc Brake
Rear Brake Disc Brake
SUSPENSION SYSTEM Front Telescopic Fork
Rear Double Shocker
TYRE Type Tubeless Tyre
Front Tyre 100/80-12”
Rear Tyre 100/80-12”
LAMPS Head Lamp LED Type
Front & Rear Direction Indicator LED Type
Tail Lamp LED Type
INSTRUMENT CLUSTER Instrument Cluster Digital
CHARGER Charger 4-7 A
